SC765 CNC High-Pressure Jet Clean Center
Versatile CNC High-Pressure Cleaning for Mid-Sized Precision Components
The SC765 CNC Jet Clean Center is engineered as the versatile powerhouse of the JCC series. Recognized as the industry standard for medium-sized components, it offers the perfect balance between a compact factory footprint and high-performance cleaning capabilities.
Equipped with a robust multi-axis CNC motion system and delivering water jets up to 70 MPa, the SC765 is designed to meet the rigorous ISO 16232 cleanliness requirements. It excels at de-burring and deep-cleaning complex internal galleries, blind holes, and cross-drilled channels in automotive valve bodies, hydraulic manifolds, and precision-machined housings.
With its enhanced chamber volume and flexible fixturing options, the SC765 provides manufacturers with the reliability and repeatability needed for high-mix, high-standard production environments.
Features
- Compact & Space-Saving Design
Maximized floor space efficiency without compromising on industrial-grade high-pressure performance. Ideal for cellular manufacturing. - 50/70 MPa Precision Jet Technology
Delivers targeted high-pressure water jets up to 70 MPa, effectively stripping away stubborn burrs, chips, and oil from complex internal geometries. - 5-Axis CNC Motion Control
Full CNC integration allows for programmable, multi-angle nozzle positioning with ±0.01mm accuracy, ensuring every critical surface is reached consistently. - ISO 16232 & VDA 19 Compliance
Specifically engineered to help manufacturers meet the highest technical cleanliness standards in the automotive and aerospace industries. - Rapid Part Changeover
Flexible fixturing and intuitive software interface enable fast setup for different workpiece types, reducing downtime in high-mix production environments. - Integrated Filtration & Recovery System
Advanced multi-stage filtration ensures the cleaning media remains pure, extending fluid life and protecting the high-pressure pump system.
Technical specifications
| MODELS | SC765 |
|---|---|
| High-pressure pump | 50MPa X 16 L/min |
| Pressure regulation | Intelligent adjustment |
| Stroke X | X=700 mm |
| Stroke Y | Y=600 mm |
| Stroke Z | Z=500 mm |
| Max. moving speed | 48m/min (X,Y,Z) |
| Positional repeatability | ±0.05mm |
| Max. spindle speed | 500 rpm |
| Nozzle quantity | 4/6 pcs |
| CNC | FANUC 0i-M F |
| Filtration system | Three-stage filtration (5μm) |
| Dimension (side) | 3320-3100-2700mm |
| Dimension (rear) | 1880-4500-2700mm |
